74 Progressa® Bed Instructions for Use (171528 REV 9)
To Stow:
Pull up on the IV pole, and fold it down toward the center of the bed.
To Use:
Pull up on the IV pole from the stowed position so that it is in the vertical position. The IV pole will
then move down to lock in the vertical position.
VERTICAL OXYGEN TANK HOLDER
The oxygen tank holders are located in the head end corners of the upper
frame. The blue sleeve holds a steel tank and the gray sleeve holds an
aluminum tank. Each oxygen tank holder accommodates one D-size or E-
size oxygen tank with a regulator.
If the optional oxygen tank holders are not installed, then this space will be
covered.
WARNING:
Warning—Each vertical oxygen tank holder safe working load is 30 lb (13.6
kg). Exceeding the safe working load can cause injury or equipment damage.
To Install:
Install the oxygen tank in the holder. Depending on the date of manufacture,
the holder will have either a rigid plastic bottom or a spring-loaded metal
support cage.
If the holder has a spring-loaded metal support cage, make sure that the
support cage completely lowers when you install the tank.
To Remove:
Lift the tank out of the holder.
NOTE:
A blue insert sleeve is required for steel oxygen tanks. A gray insert sleeve is required for aluminum
oxygen tanks.
KINETEC® OXYGEN TANK HOLDER
The Kinetec® oxygen tank holder is a removable tank holder that can be installed at the head end of the
bed, in the left or right IV pole sockets. The oxygen tank holder accommodates cylinder type B5 with a
regulator.
WARNING:
Warning—Make sure the headboard is installed when the oxygen tank holder is in place. Patient injury
may occur.
To Install:
Install the oxygen tank holder in the left or right IV pole socket. Make sure the openings in the
holder align with the space in the bed frame.
To Remove:
Lift the holder out of the IV pole socket.
