Caregiver Siderail Controls
20 Progressa® Bed Instructions for Use (171528 REV 9)
Warning—Do not use ankle restraints when you activate this feature; injury to the patient may occur.
TRENDELENBURG OR REVERSE TRENDELENBURG
The Progressa® Bed is capable of 13° Trendelenburg. Reverse Trendelenburg can achieve 18° (beds
without Chair Egress) or 20° (beds with Chair Egress). The powered Trendelenburg and Reverse
Trendelenburg controls can be activated at any bed height.
Retract foot section to achieve full Reverse Trendelenburg.
Warning—Trendelenburg/Reverse Trendelenburg may cause linens, drainage bags, and other
equipment to come in contact with the floor. Follow facility protocol if they touch the floor. Injury could
occur.
Caution—While articulating in Trendelenburg position, make sure there is adequate headwall
clearance. Equipment damage may occur.
To Activate
• Trendelenburg - Press and hold the Trendelenburg control. The foot end of
the bed raises relative to the head end.
• Reverse Trendelenburg - Press and hold the Reverse Trendelenburg control.
The head end of the bed raises relative to the foot end.
To Deactivate
• Return to flat position - Press the opposite control. (If in Trendelenburg -
press Reverse Trendelenburg. If in Reverse Trendelenburg - press
Trendelenburg.) When the level position is reached, the bed will pause. You
can also press the Bed Flat control (refer to “Bed Flat Control” on page 24).
If the foot section is in the down position when Reverse Trendelenburg is
activated, the foot section will automatically raise. This prevents the articulated
foot section from interfering with the floor.
The Progressa® Bed will not move to the Trendelenburg/ Reverse Trendelenburg position if the bed
up/down controls are locked out.
BOOST® POSITION SYSTEM
The Boost® Position System assists with the movement of the patient to the head end of the bed.
The Boost® Position System will not work if the bed up down controls are locked out.
