3rd edition service kits for a subsequent component failure
Use this table to determine the correct part to order if you encounter a component failure after
upgrading using the components in the 3rd edition service kit for first component failure.
NOTE For a first component failure, refer to the 3rd edition service kits for a first
component failure table.
Device
Model
Number
Main
Board
SureTe
mp Plus
Masimo Nellcor Nonin Braun
Dock
Braun Thermometer
7*CE, 7*CT,
7*CX, 7*ME,
7*MT, 7*MX,
7*XE, 7*XT,
7*XX, 7*WE,
7*WT, 7*WX
105925 105940 105931 105932 105933 105941 105948
*Varies depending on the model number of your device.
List of 3rd edition service kits
To determine the correct replacement part for your unit, always provide the serial number and
model when ordering.
Service Kit
Number
Material
Number
Description
1 105945 Srv Kit CSM, Battery Door
2 Batt22 Srv Kit 2 Cell Lithium-ion Battery
3 105923 Srv Kit CSM, Back Housing*
4 105939 Srv Kit CSM, End Cap
5 105942 Srv Kit CSM, Speaker
6 105920 Srv Kit CSM, NIBP Pump Assembly
7 105933 Srv Kit CSM, Nonin SpO2 PCBA
8 105931 Srv Kit CSM, Masimo SpO2 PCBA
9 105932 Srv Kit CSM, Nellcor SpO2 PCBA
10 105925 Srv Kit CSM, Main PCA, and LCD Frame
11 105930 Srv Kit CSM, Power Harness
12 105938 Srv Kit CSM, Newmar Antenna PCBA
13 105936 Srv Kit CSM, Newmar Radio PCBA
94 Field replaceable units Welch Allyn® Connex® Spot Monitor
