ENGLISH
7.3.1.3 LED indication
RAS-(2/2.5/3)WHVRP1 and RASM-(2/3)VRE)
Name Colour Indication
PCB1
LED1 Red Power
LED2 Green Communication with inverter
LED3 Yellow H-LINK transmission
LED4 Yellow Not used
LED351 Red For inspection
LED353 Red For inspection
PCB2
LD1 Red For inspection
LD2 Red For inspection
LD3 Red For inspection
LD4 Red For inspection
RAS-(4-10)WH(V)NPE and RASM-(4-6)(V)NE
LED Indication
LED1 Red This LED indicates the transmission status between the indoor unit and the unit controller
LED2 Yellow This LED indicates the transmission status between the indoor unit and the outdoor unit
LED3 Green Power source for the PCB
ELECTRICAL AND CONTROL SETTINGS
PMML0575 rev.2 - 03/2022
87
