Honeywell 35 Series Network Video Recorder User Guide
6
Table 5 NVR Rear Panel Description (HN35040100N & HN35080100N)
No. Name Description
1 LAN1
Network port. 10M/100Mbps self-adaptive Ethernet port.
Connect to the network cable.
2 LAN2
Connect to the network cable, LAN2 port is only allowed to
connect cameras, cannot to connect to Internet.
3 AUDIO OUT
Audio output port. It is to output the analog audio signal
to the devices such as the sound box.
•
Bidirectional talk output.
•
Audio output on 1-window video monitor.
Audio output on 1-window video playback.
4 AUDIO IN
Bidirectional talk input port. It is to receive the analog
audio signal output from the devices such as microphone,
pickup.
5 VGA
VGA video output port. Output analog video signal. It can
connect to the monitor to view analog video.
6 HDMI
High definition audio and video signal output port. It
transmits uncompressed high definition video and
multiple-channel data to the HDMI port of the display
device. HDMI version is 1.4.
7 ALARM I/O
They receive signals from external alarm source. C is COM
port. There is one channel of alarm in; There are four
channels of alarm out.
When your alarm input device is using external power,
make sure the device and the NVR have the same GND.
8 Power switch Power on/off button.
9 Power input port Power socket.
10
GND
