Honeywell 35 Series User Manual

Honeywell 35 Series Network Video Recorder User Guide
35
5. Choose the type of protocol. The default value is RTSP. Input the port
which depends on the IP camera.
6. Input the path, it depends on the manufacturer of cameras.
7. Click APPLY to save the settings.
Encode
You can set video bit stream parameters such as video format, resolution,
frame rate(fps), and so on.
Note:
Some series products support three streams: main stream, sub stream
1, sub stream 2. The sub stream maximally supports 1080p.
1. Go to Main Menu > Camera > Encode.
The Encode interface is displayed.
Figure 41 Encode
2. Configure parameters.
Table 14 Audio/Video Parameters
Parameter Description
Channel
In the Channel list, select the channel that you want to configure the
settings for.
Smart encode
Enable the smart encode function to reduce the video bit stream for non-
important recorded video to maximize the storage space.
Video format
In the Compression list, select the encode mode.
H.265: Main profile encoding. This setting is recommended.
H.264: Main profile encoding.
Resolution
In the Resolution list, select resolution for the video.
The maximum video resolution might be different dependent on your
device model.

Honeywell 35 Series Specifications

General

Video Compression	H.264
Night Vision	Yes
Power Source	Wired
Motion Detection	Yes
Storage	MicroSD card (up to 128GB)
Weather Resistance	Yes
Lens	2.8mm
