Honeywell 35 Series Network Video Recorder User Guide
36
Parameter Description
Frame rate (fps)
Configure the frames per second for the video. The higher the value is, the
clearer and smoother the image will become. Frame rate changes along
with the resolution.
Generally, in PAL format, you can select the value from 1 through 25; in
NTSC format, you can select the value from 1 through 30. However, the
actual range of frame rate that you can select depends on the capability of
the device.
The NVR supports up to 30 fps, if the adding cameras’ capability are over
30 fps, the NVR will degrade them to 30 fps.
I frame
interval(frame)
The interval between two reference frames.
Bitrate type
In the Bit Rate Type list, select CBR (Constant Bit Rate) or VBR (Variable
Bit Rate). If you select CBR, the image quality cannot be configured; if you
select VBR, the image quality can be configured.
Bitrate(kbps)
Indicates the maximum value of the bit rate. You can input the value which
can’t be bigger than the biggest value from drop-down list), otherwise the
value is invalid. Or you can choose value from drop-down list.
Quality
This function is available if you select VBR in the Bit Rate List.
The bigger the value is, the better the image will become.
3. Click APPLY to complete settings.
Sensor Setting
1. Go to Main Menu > Camera > Sensor Setting.
The Sensor Setting interface is displayed
Figure 42 Image
2. Configure parameters.
