2. OVERVIEW
2.3.5 Sunshade
Part Number: 2110B2152
115mm
145mm
The Sunshade prevents excessive heating of the sensor by direct sunlight. Conforms to CSA C22.2
No. 152whenttedtotheCertiedSensorwithspeciccartridgesinstalled.Seespecications
for details.
Thesunshadeisttedtothesensorbodybymeansofaclamp.
2.3.6 Oxygen Transducer Adaptor
The Oxygen Transducer Adaptor is supplied with the Oxygen cartridge and is necessary because the
depth of the Oxygen cartridge is more than that of the other gas cartridges.
TheadaptorisattachedtotheCertiedSensorbymeansofabayonettting.TheOxygencartridgeis
ttedrstandthesensorcaporaccessoryisthenttedtotheadaptorbymeansofabayonettting.
2.3.7 Filters
OneofthreedifferenttypesoflteraccessorycanbettedtotheCertiedSensorinplaceoftherubber
seal inside the sensor cap or accessory.
Thethreedifferenttypesoflteravailableare:
Mesh lter - Part Number: 2110B2170 - for use in harsh
 environments.Thelterpreventsdirtfromblockingthe
cartridge sinter.
Hydrophobic lter - Part Number: 2110B2171 - for use
in environments where the cartridge front is likely to become
wet. The hydrophobic material allows gas to pass through but
 notwater.AhydrophobiclterissuppliedwiththeFlow
Housing and must beusedwhencalibratingsensorstted
 withammablegascartridges.
Caution: Thesensitivityofsomecartridgesmaybedegradedbythehydrophobiclter.
Carbon lter - Part Number: 2110B2172-foruseinenvironmentswheresignicant
 volatilecompoundsarepresent.Thelterpreventsthecartridgefrombeingcritically
affected.
53mm
18mm
