Honeywell Apex - User Tasks Reference Guide

77
MAN0604_Issue 09_02-2013 Apex
2110M8030
4. OPERATION
(up, down, ok, esc, esc, ok, down, up)
4.5 USER TASKS
The following table provides a quick reference list of typical tasks and how to carry them out via the
menu system.
Tasks related to: Sub-Menu Sub-Menu Option User Level
4-20mA loop
 SetInhibit,WarningandOverrangelevels Conguration Congure4-20mA 2
 Zerosetting  Calibration 4-20mASetZero  2
 Testoperation  Calibration Force4-20mA  2
Alarms
 Setoverrangelatchingonoroff Conguration CongureAlarms  2
 Setgasalarmlevels  Conguration CongureAlarms  2
Reset alarms Display Reset Alarms 1
Checking the unit’s settings
Calibration settings Display Calibration Information 1
 Congurationsettings  Display CurrentConguration 1
Checking the unit’s operational history
View the unit's log History Log View History Log 2
Clearing the history log History Log Reset History Log 2
Digital communications
 Viewsettings  CongurationCongureDigital  2
 Registerthecommunicationsboard CongurationCongureDigital  2
Test operation Calibration Force Digital 2
Display Screen
 Turnbacklighton/off*  Conguration CongureBacklight 2
Changetheon-screendisplaylanguage Conguration SelectLanguage  2
Gas
Test unit with gas Calibration Gas Challenge 2
 Changeagassensorcartridge Conguration ChangeCartridge 2
Calibrate gas Calibration Gas Calibrate 2
Passwords
Change a password Change Passwords Level 1 Password 3
Change Passwords Level 2 Password 3
Change Passwords Level 3 Password 3
Reset all passwords to default Reset passwords 3
Relays
 Set-uprelaycontacts  Conguration CongureRelays  2
Test relays Calibration Force Relays 2
* The Congure Backlight controlisnotavailableonCSACertiedTransmitterUnits.
