Honeywell Apex User Manual

28
MAN0604_Issue 09_02-2013 Apex
2110M8030
3. INSTALLATION
Caution: Do not force the cartridge as this may cause damage to the pins of the connecting
plugs. Twisting and pushing can bend the pins and make the cartridge inoperative.
Socket (2 off)
Locating
tab
recess
Sensor body
Plug
(2 off)
Locating
tab
Cartridge
Note: IfttinganOxygencartridgeensurethattheOxygenTransducerAdaptorsuppliedwiththe
OxygencartridgeisttedtotheCertiedSensorbody.Theadaptoristtedtothesensor
bodyviaabayonettting.
(3) RetthecaptotheCertiedSensor.
Reverse the removal procedure.
(4) Check for correct operation of the system by carrying out the procedures described in
Chapter 4.
Sensor body
Cartridge fitted to sensor
body
Sensor cap
