4. OPERATION
Main Menu
Calibration Menu
Configuration Menu
Display Menu
History Log Menu
Change Passwords Menu
Reset Passwords
Calibration Menu
Gas Calibrate
Gas Challenge
4-20 mA Set Zero
Force 4-20mA
Force Relays
Force Digital
Configuration Menu
Change Cartridge
Configure 4-20mA
Configure Relays
Configure Alarms
Configure Digital
Select Language
Configure Backlight
Display Menu
Reset Alarms, Faults
Calibration Info
Current Config
History Log Menu
View History Log
Reset History Log
Change Passwords Menu
Level 1 Password
Level 2 Password
Level 3 Password
The subsequent subsections describe each of the main menu options in turn and show, using a
owchartformat,howtoaccessandimplementtheirsub-options.
Thefollowingsymbolsareusedontheowchartdiagrams:
GasCalibrate
Sub-menu option selected.
Zero Calibration screen
Sub-menu action.
User action.
Calibrating
System process.
Success?
Decision.
Use up/down
buttons
Comment/instruction.
Button press.
Zero Gas
