Honeywell EXCEL 5000 User Manual

ALPHABETIC REFERENCE EXCEL CARE CONTROL ICONS
74-5577–33 (US) 150
EN2B-0184 GE51 R0518 (Europe)
On-Board DO (Excel Web / Excel Web II)
Function Write on-board digital output of the Excel Web / Excel Web II controller main board.
I/O Dialog Box
Input One digital input (X).
Output None.
Internal Parameters None.
On/Off Delay (Excel Web / Excel Web II)
Function Switch On- and Off delay of input A to output Y. The Off-Delay extends the time
period of the signal. You can create either an On- or Off delay logic or apply both
delays.
I/O Dialog Box
Input One digital input (A).
Output One digital output (Y)
Internal Parameters None.
On_Delay Example
Off-Delay Example
