Honeywell EXCEL 5000 User Manual

ALPHABETIC REFERENCE EXCEL CARE CONTROL ICONS
74-5577–33 (US) 38
EN2B-0184 GE51 R0518 (Europe)
Cycle / CYC
Function Puts out a digital value (0 or 1) on a cyclic basis.
I/O Dialog Box
Excel Web / Excel Web II
Input One digital input (XD, Excel Web / Excel Web II: X), required.
Output One digital output (YD, Excel Web / Excel Web II: Y).
Internal Parameters
Excel Web / Excel Web II
On time: Number type: whole number, Unit: Seconds
Default: 20 sec, Range: 0 through 7200 sec
This value defines the duration of the high impulse level (impulse width).
CAUTION
Zero, 0, is a legal value but should not be used because it disables the timer
and does not accept on-line changes.
Off time: Number type: Whole number, Unit: Seconds
Default: 0 sec, Range: 0 through 7200 sec
This value defines the duration of the low impulse level (impulse pause).
Parameter Number
