Honeywell EXCEL 5000 User Manual

EXCEL CARE CONTROL ICONS ALPHABETIC REFERENCE
149 74-5577–33 (US)
EN2B-0184 GE51 R0518 (Europe)
NOT (Excel Web / Excel Web II)
Function Negates the binary input value.
I/O Dialog Box
Inputs One digital input (X).
Output One digital output (X-), containing the negated input.
Internal Parameters None.
Odd Parity (Excel Web / Excel Web II)
Function Compares binary values and returns TRUE(1), if the number of TRUE(1) elements
are odd.
I/O Box Dialog
Inputs Two through thirty two digital inputs.
Output One digital output (Odd).
Internal Parameters None.
On-Board DI (Excel Web / Excel Web II)
Function Read on-board digital input of the Excel Web / Excel Web II controller main board.
I/O Dialog Box
Input None.
Output One digital output (Y), containing status of on-board digital input.
Internal Parameters None.
