EXCEL CARE CONTROL ICONS ALPHABETIC REFERENCE
237 74-5577–33 (US)
EN2B-0184 GE51 R0518 (Europe)
X root Y (Excel Web / Excel Web II)
Function Calculates X to the root of Y.
I/O Dialog Box
Input Two analog inputs (Y, X).
Output One analog output (X root Y).
Internal Parameters None.
X^2 (Excel Web / Excel Web II)
Function Calculates the product X * X.
I/O Dialog Box
Input One analog input (X).
Output One analog output (X^2).
Internal Parameters None.
X^Y (Excel Web / Excel Web II)
Function Calculates X to the power of Y.
I/O Dialog Box
Input Two analog inputs, where
X = base
Y = exponent
Output One analog output (X^Y).
Internal Parameters None.
XOR Table (Excel Web / Excel Web II)
Function XOR output becomes TRUE(1) if exactly one input is TRUE(1). XNOR is the
inverted XOR output.
