EXCEL CARE CONROL ICONS
21 74-5577–28 (US)
EN2B-0184 GE51 R1114 (Europe)
ALPHABETIC REFERENCE
Chapter Contents This chapter describes each control icon as follows:
Function Statement of control icon purpose.
Formula Formula related to icon, if any.
I/O Dialog Box Reproduction of the I/O dialog box that displays in the control
strategy work space for selection of control icon inputs and
outputs.
Inputs Description of required inputs.
Outputs Description of required outputs.
Internal
Parameters Description of the icon’s internal parameters dialog box that
xdisplays for entry of the parameters in the Control strategy work
space. Not all control icons have an internal parameters dialog
box.
Parameter
Number
Descriptions Parameter number assignments. Parameters are identified with
a P and a number, for example, P3, P4. The parameter list file
generated during CARE translation documents control icon
parameters and references them via these numbers. See
Appendix A: Parameter List Description for more information
about the list file.
Note that parameters 1 and 2 are reserved for system use.
Therefore, all parameters described for the control icons start at
number 3.
Operation Some icons have an operation section that details special steps
or provides a functional description of the icon.
Example(s) Sample application(s) of icon.
See Also ⇒ Control Icon Operation in the Introduction chapter for a general description of the I/O
dialog box and the internal parameters dialog box
Examples chapter for descriptions of applications that use multiple icons
