EXCEL CARE CONTROL ICONS ALPHABETIC REFERENCE
101 74-5577–33 (US)
EN2B-0184 GE51 R0518 (Europe)
Select the Extrapolation algorithm by setting Parameter P9 to the value 3.
A safety margin parameter (P6) provides a secure margin between the current
power peak (Parameter P1) and the possible power (Parameter P4).
The internal user address IA___Energy_Intv indicates current energy consumed
(equal to Z
7
- Z
0
in the previous diagram) during the measurement interval. The
General Functions subsection explains the other internal user addresses and
parameters used in this algorithm.
The following table lists parameters used for the extrapolation algorithm.
Parameter
Number
Type
Brief Description
Setting
Range
Default
Value
Unit
1 Display Current Power Consumption none none kW
2 Display Remaining Rest Time none none min
3 Display Remaining Work none none kWh
4 Display Possible Power with constant
Power Consumption
none none kW
6 Comm. Safety Margin 0-1000 0 kW
9 Comm. Measurement Algorithm
3=Extrapolation
1/2/3 3 Integer
10 Comm. Measurement Interval/Window Size 1-7200 15 min
13 Comm. Power Limit 1
0-10
6
10000 kW
14 Comm. Power Limit 2
0-10
6
10000 kW
