Configuring via the Web Server
Configuring Interlocks
NetAXS™ Access Control Unit User’s Guide, Document 800-00233, Revision A 2-51
2.8 Configuring Interlocks
An interlock is a programmed connection between two points. The interlock causes an input point,
output point, or group of output points to act in a specified manner when another input point, output
point, or group of output points changes its state. An action on one point cause a reaction from a
second point on the same panel or attached MIRO board. For example, when a motion detector (input)
detects movement, it causes a horn (output) to sound.
Click
Interlocks to display the Interlocks Configuration screen:
Figure 2-23: Configuration > Interlocks
The Interlocks screen enables you to:
• Create, modify, and delete interlocks.
• Enable or disable existing interlocks.
