4-6 www.honeywell.com
Monitoring NetAXS™ Status
Monitoring Events
Click Status > Events > Web to display the Web events tab:
Figure 4-4: Status > Events > Web Tab
Notes:
• The number of active users is indicated in the upper left corner of the tab.
• You can display the oldest events first by clicking
Oldest at the bottom of the tab, or display the
newest events first by clicking
Newest. Click Older to scroll through the list by displaying the
next oldest tab display of events.
PN Physical device number – the unique number assigned to the
device on the NetAXS™ board.
Code Briefly describes the event.
Credential Identifies the card number.
Card Holder Name Identifies the last name of the card holder who energized the
input device when the alarm was generated.
Table 4-2: Status > Events > Panel Tab Field Descriptions (continued)
Column Head Description
