Monitoring NetAXS™ Status
Monitoring Events
NetAXS™ Access Control Unit User’s Guide, Document 800-00233, Revision A 4-5
4.3 Monitoring Events
The Events page monitors both panel- and web-generated events. For example, a panel event is the
reading of a card by a reader. A web event example is a user logon.
Click
Status > Events to display the Panel event tab:
Figure 4-3: Status > Events > Panel Tab
The following table describes the information displayed on the Panel events tab:
Table 4-2: Status > Events > Panel Tab Field Descriptions
Column Head Description
Date/Time [ID] Provides the date and exact time the event was generated,
according to the panel’s name.
Device Name [ID] Identifies the device that generated the event.
LN
Logical device number – the unique name or number given to
the event-generating device when the device was configured in
Configuration > Doors.

Honeywell NetAXS Specifications

General

Category	Control Unit
Max. Number of Doors	4
Max. Number of Readers	8
Inputs	8
Outputs	4
Users	10, 000
Transaction Buffer	50, 000
Operating Voltage	12-24 VDC
Network Interface	10/100 Mbps Ethernet
Reader Technology	Magnetic Stripe, Barcode, Proximity, Smart Card
Communication	TCP/IP, RS-485
Humidity	5% to 85% RH, non-condensing
Weight	3.5 lbs
Certifications	UL294, CE, FCC
Dimensions	165 mm x 140 mm x 40 mm (6.5" x 5.5" x 1.6")
