Honeywell NetAXS User Manual

4-4 www.honeywell.com
Monitoring NetAXS™ Status
Monitoring Alarms
Note: You can display the oldest alarms first by clicking Oldest, or display the newest alarms first by
clicking
Newest. Click Older to scroll through the list by displaying the next oldest tab display of
alarms.
LN Logical device number – the unique name or number given to
the alarm-generating device when the device was configured in
Configuration > Doors.
PN
Physical device number – the unique number assigned to the
device on the NetAXS™ board.
Code Identifies the current state of the device that generated the alarm.
For example, the possible states could include:
• Normal State
•Alarm State
•Ajar State
•Card Found
• Card Not Found?
Credential Identifies the card number.
Card Holder Name Identifies the last name of the card holder who energized the
input device when the alarm was generated.
Table 4-1: Status > Alarms Field Descriptions (continued)
Column Head Description

Honeywell NetAXS Specifications

General

Category	Control Unit
Max. Number of Doors	4
Max. Number of Readers	8
Inputs	8
Outputs	4
Users	10, 000
Transaction Buffer	50, 000
Operating Voltage	12-24 VDC
Network Interface	10/100 Mbps Ethernet
Reader Technology	Magnetic Stripe, Barcode, Proximity, Smart Card
Communication	TCP/IP, RS-485
Humidity	5% to 85% RH, non-condensing
Weight	3.5 lbs
Certifications	UL294, CE, FCC
Dimensions	165 mm x 140 mm x 40 mm (6.5" x 5.5" x 1.6")
