Honeywell NetAXS User Manual

NetAXS Access Control Unit User’s Guide, Document 80000233, Revision A vii
LIST OF TABLES
Table 1-1: Reading the Select Panel .........................................................................................1-8
Table 2-1: Configuration > System > General Tab Fields .......................................................2-3
Table 2-2: Configuration > System > Host/Loop Communications Tab Field Descriptions .2-13
Table 2-3: Configuration > Time Management Tab Field Descriptions ................................2-16
Table 2-4: Configuration > Doors > Reader Tab Descriptions ..............................................2-23
Table 2-5: Configuration > Doors > Reader > Card Format Fields .......................................2-25
Table 2-6: Configuration > Doors > Output Tab Field Descriptions .....................................2-29
Table 2-7: Configuration > Doors > Inputs Tab Field Descriptions ......................................2-33
Table 2-8: Cards > Add Cards Field Descriptions .................................................................2-37
Table 2-9: Cards > Reports Field Descriptions ......................................................................2-41
Table 2-10: Configuration > Other I/O & Groups > Inputs Tab Field Descriptions ..............2-45
Table 2-11: Configuration > Other I/O & Groups > Outputs Tab > Fields ...........................2-48
Table 2-12: Configuration > Other I/O & Groups > Groups Tab Field Descriptions ............2-50
Table 2-13: Configuration > Interlocks > Field Descriptions ................................................2-52
Table 3-1: Interlock Reassignments for NetAXSs™ ...............................................................3-8
Table 4-1: Status > Alarms Field Descriptions ........................................................................4-3
Table 4-2: Status > Events > Panel Tab Field Descriptions .....................................................4-5

Honeywell NetAXS Specifications

General

Category	Control Unit
Max. Number of Doors	4
Max. Number of Readers	8
Inputs	8
Outputs	4
Users	10, 000
Transaction Buffer	50, 000
Operating Voltage	12-24 VDC
Network Interface	10/100 Mbps Ethernet
Reader Technology	Magnetic Stripe, Barcode, Proximity, Smart Card
Communication	TCP/IP, RS-485
Humidity	5% to 85% RH, non-condensing
Weight	3.5 lbs
Certifications	UL294, CE, FCC
Dimensions	165 mm x 140 mm x 40 mm (6.5" x 5.5" x 1.6")
