Configuring via WIN-PAK
Adding a New NetAXS™ Panel
NetAXS™ Access Control Unit User’s Guide, Document 800-00233, Revision A 3-9
The screen captures shown below show the configuration for the default
interlocking for a single door:
11 Reader 3 tamper/auxiliary.
12 Reader 4 tamper/auxiliary.
13 Primary power status - external (or General input). There is
also a system primary power alarm 17 that reports through
the ADV and is not a wired port.
14 Tamper (or General input).
Table 3-1: Interlock Reassignments for NetAXSs™ (continued)
Interlock Function
