NFS2-3030 Programming Manual — P/N 52545:A 11/29/2005 29
Panel Program Program
Soft Keys
ANNUNCIATOR TYPE: When the cursor is placed at the desired address, press this soft key to
scroll through the following list of types. Stop at the appropriate type.
POINT PROGRAMMING: Press this soft key to proceed to the ACS Point Programming screen.
ACCEPT: Press this soft key to save all the changes made and return to the previous screen (Panel
Program).
ACS Point Programming
ACS Point Programming can be reached by pressing POINT PROGRAMMING at the ACS
Programming screen. This screen allows the programmer to assign a mode and sources to each
annunciator point at the annunciator address. One ACS input may be used to control multiple SLC
output modules by listing the output points in the SOURCE fields. This feature applies to the
following Types: 64PT, 64SYS, 64SVC, 96PT, 96SYS, 96SVC, and 96DCC.
Type Used for
64PT 64 point annunciation
64SYS 64 point annunciation, with first 8 points reserved
64SVC
*
* Two Level Bypass: When an ACS board is programmed as a 64SVC or 96SVC type,
the operator must enter the Program/Alter Status mode of operation before pressing any
push buttons to control points on these boards. If a push button is pressed while not
in
the Program/Alter Status screen, and no unacknowledged events exist, the password
screen will automatically be displayed so the operator can enter the Program/Alter
Status mode.
64-point service mode for Two Level Bypass
96PT 96 point annunciation
96SYS 96 point annunciation, with first 8 points reserved
96SVC* 96-point service mode for Two Level Bypass
96DCC 96 point annunciation to be used with multiple Command Centers
UDACT UDACT, first address. Any additional UDACT annunciator addresses should be programmed as
64PT and be sequential.
TM4 TM-4
AMG
†
† AMG Addressing: When using an AMG, the address it occupies (an address of 25
through 32, typically address 32) must be set to annunciator type AMG, and address
one must be set to annunciator type 64PT.
AMG
FSCS Smoke control modules set for FSCS mode
HVAC Smoke control modules set for HVAC mode
UZC Universal Zone Coder, first address. Any additional UZC annunciator addresses should be
programmed as 64PT and be sequential.
NOTE: SLC output modules with releasing Type IDs may not be listed in the annunciator source
fields.
NOTE: The NFS2-3030 supports ACM-24AT/ACM-48A annunciators and their expanders with
either 64 or 96 points at an address, as well as ACM-16AT/ACM-32A/LDM-32 annunciators with
64 points at an address.
