Program Point Program
designations. For example, SLC inputs with“fire” point types will activate SLC outputs with“fire”
point types. Refer to Appendix G.3, “Type Codes for Input Devices”, on page 127 for Type Code
point types. Default: OFF
ACCEPT: Press to save entries made on this screen and to return to the previous screen.
Module Point Programming (Control Module)
Pressing the MORE soft key at the Module Point Programming screen will display this screen if the
module type was control.
Figure 3.34 Module Point Programming Screen 2 (Control)
Soft Keys
ZONE MAP: Displays the zones mapped to this point. The default value assigned to control modules
during initial programming is Z000 at Position 1 (refer to Figure 3.34), with the exception of control modules
with the following Type IDs: Telephone, Gen Alarm, Gen Supervis, Gen Trouble, and Trouble Pend.
To add or delete zones, press this soft key to proceed to the Module Zone Map screen. Refer to
“Zone Map” on page 41 for an illustration and explanation of the Detector Zone Map screen. The
Module Zone Map screen is the same except that Module replaces Detector in the title and the
module address appears instead of the detector address. Up to ten general, logic, release, special or
trouble zones may be mapped to a control module. Position 1 has additional functionality.
Position 1 - This position is checked when a group zone disable command is issued. If the zone
number in the group zone disable command matches the zone number in the first position of
the zone map, the module point will be disabled.
Note that the group zone disable command has no effect on general alarm zone Z000.
NOTE: The panel setting LCM LOCAL MODE must be set to Yes for local mode to work at the
device level.
MODULE POINT PROGRAMMING
L03M150
ZONE MAP:
Z000 , Z104 , Z105 , Z106 , Z107
Z110 , Z114 , Z115 , Z116 , Z117
WALK TEST: OFF LOCAL MODE:ON
SWITCH INHIBIT: YES ACCEPT
SILENCEABLE:NO BACK
Zone Map Position 1 - Use for group zone
disable participation.
To Next Page
