Thor VM1 with Microsoft Windows Embedded Standard 2009 User Guide 171
Note: Tap the Commit button to save changes. If this panel is closed before tapping the Commit
button, changes are not saved!
Logon Options
There are two options available, a Single Signon option which uses the Windows user-
name and password as the credentials for 802.1x authentication and a Pre-Logon
Connection option which uses saved credentials for 802.1x authentication before Win-
dows logon.
If either option is enabled, the credentials entered here take precedence over any cre-
dentials entered on the Profile tab.
To use either option, select Logon Options from the Property list which activates the
Logon Options button.
Hide Password On When On, the Summit Config Utility masks passwords (characters
on the screen are displayed as an *) as they are typed and when they
are viewed. When Off, password characters are not masked.
Options are: On, Off.
Admin Password SUMMIT
(or Blank)
A string of up to 64 alphanumeric characters that must be entered
when the Admin Login button is tapped. If Hide Password is On, the
password is masked when typed in the Admin Password Entry dialog
box. The password is case sensitive. This value is masked when the
Admin is logged out.
Options are: none.
Auth Timeout 8 seconds Specifies the number of seconds the Summit software waits for an
EAP authentication request to succeed or fail.
If the authentication credentials are stored in the active profile and
the authentication times out, the association fails. No error
message or prompting for corrected credentials is displayed.
If the authentication credentials are not stored in the active profile
and the authentication times out, the user is again prompted to
enter the credentials.
Options are: An integer from 3 to 60.
Certs Path certificates A valid directory path, of up to 64 characters, where WPA Certificate
Authority and User Certificates are stored on the mobile device
when not using the Windows certificates store. Ensure the Windows
folder path exists before assigning the path in this parameter. See
Certificates for instructions on obtaining CA and User Certificates.
This value is masked when the Admin is logged out.
Options are: none.
The complete path is C:\Program Files\Summit\certs
Ping Payload 32 bytes Maximum amount of data to be transmitted on a ping.
Options are: 32 bytes, 64, 128, 256, 512, or 1024 bytes.
Ping Timeout ms 5000 The amount of time, in milliseconds, that a device will be
continuously pinged. The Stop Ping button can be tapped to end
the ping process ahead of the ping timeout.
Options are: Any number between 0 and 30000 ms.
Ping Delay ms 1000 The amount of time, in milliseconds, between each ping after a
Start Ping button tap.
Options are: Any number between 0 and 30000 ms.
Logon Options SCU Use SCU or Windows login credentials.
Parameter Default Function
