124Honeywell, Issue 9
March 2007
XLS80e Fire Alarm Control Panels
15.2 Virtual Input Points
1 Enter the point number.
2 Enter a zone number. Virtual points must
be allocated to a zone to be useable within
the Control Matrix. If the point number
entered in step 1 was for an existing point,
it can be deleted by entering ‘0’. A ‘press to
confirm’ prompt is displayed.
3 Select the point type, either ALARM or AUX.
This determines whether activation of the
point is displayed on the Fire tab or on the
Aux tab.
Note: If Virtual Input Points are to be used in
the Control Matrix, those to be used as
Alarm inputs must be configured as type
ALARM, and those to be used as Non-
fire Activation inputs must be configured
as type AUX.
4 Use the Text Editor to enter the Virtual Input
Point name (see Section 6.1). The Virtual
Point Configuration options are then
redisplayed.
15.3 Virtual Output Backup Sounder
This option is only displayed if one or more
Virtual Output Points has already been
configured and assigned to a zone.
Select which sounder circuit is to be used as
a backup for the Virtual Output(s), or 0 if none.
The Virtual Point Configuration options are
then redisplayed.
Virtual Point Configuration
1:Virtual Output Point
2:Virtual Input Point
NUMERIC
ENTRY, THEN
Virtual Point Configuration
Virtual Input no. (1-64): n
NUMERIC
ENTRY, THEN
CONFIRM CHANGE. THE TEXT EDITOR IS
THEN DISPLAYED
Virtual Point Configuration
Virtual Input Point 11
ALARM
Place in Zone (1-255):
(0 = Delete Virtual Point)
0
CONFIRM CHANGE
Virtual Point Configuration
Virtual Input Point 11
ALARM
Place in Zone (1-255): 75
Press to confirm, X to cancel
Virtual Point Configuration
Virtual Input Point 11
ALARM
Set Virtual Input Point Type:
1:
2:AUX INPUT
Normal Alarm Input
Virtual Point Configuration
Select Sounder Circuit to be Backup
for Virtual Output (1-4; 0=none): 1
Virtual Point Configuration
1:Virtual Output Point
2:Virtual Input Point
3:Virtual Output Backup Sounder
To Next Page
