Honeywell XLS80e User Manual

59 Honeywell, Issue 9
March 2007
XLS80e Fire Alarm Control Panels
7.4 Output Modes
In addition to its category (see Section 7.3),
you may configure the output to operate in one
of four modes. These give combinations of
immediate or delayed, steady or pulse
operation, where:
Delay is user-programmable up to
10 minutes in 5 second intervals.
Steady = continuous.
Pulse = alternating periods of either
1 second 'ON', 1 second 'OFF', or the user-
defined pulsing periods (see Section 11.4,
Pulsing Sounder Modes).
Neither pulse nor delay are applicable for
certain categories of input.
For example, the silence/resound action for
sounders is pre-defined and need not be
programmed.
OUTPUT MODES:
i
ii
iii
iv
INPUT OUTPUT
IF INPUT IS:
THEN OUTPUT IS ALWAYS:
SINGLE 5-SECOND
PULSE, THEN ‘OFF’
OR
OR
A
C
A
B
B
C
0
9
8
7
6
5
1
2
3
4
0
9
8
7
6
5
1
2
3
4
0
9
8
7
6
5
1
2
3
4
0
9
8
7
6
5
1
2
3
4
x10
x10
x1
x1
2111098 7
2
11
10
9
8
7
2111098 7
6
5
4
3
2
1
6 5 4 3 2 1
