An active border or edge nozzle of the respec-
tive folding boom wing is displayed here on
the main page of the terminal.
Prerequisites for the use of automatic nozzle control:
Automatic nozzle control can only be selected if the speed ranges of the activated nozzles overlap:
F
The graphic shows whether the ranges of the
nozzle proles overlap.
Proles activated for automatic nozzle control
are shown in green, deactivated proles in red.
Manual nozzle control
NOTE
With manual nozzle control only the nozzles selected by touching are active. There is no automatic
changeover to other nozzle proles.
The correct selection of the nozzles for the respective travel speeds and placing quantities must
be ensured by the operator!
44 45
