4.4 Additional functions
c
a
f
g
e
d
h
i
b
(a) Tank content residue drain (spraying mixture container is emptied)
¾ Remove the cap of the residue drain and put a suitable vessel for collecting the chemical
under it.
¾ Activate the residue drain function on the external control terminal.
¾ Deactivate the residue drain function again when the spraying mixture container is completely
drained.
¾ Replace the cap and dispose of the collected chemical according to regulations.
(b) Activate/deactivate NightLight cleaning (optional)
(c) Putting the sprayer system into winter storage
¾ See Chapter Winter storage of spraying system
(d) Activate/deactivate outside cleaning (optional)
(e) Activate/deactivate the working lights on the illuviation valve (optional)
(f) Cleaning the suction lter
¾ Start the Filter cleaning function on the external control terminal.
¾ A note appears on the terminal that the lter can now be cleaned/replaced.
¾ Conrm the message with “ENTER”.
¾ Clean/replace the suction lter. Collect the deposits with a suitable container and dispose of
them according to regulations.
¾ Screw in the lter again.
¾ Disable the lter cleaning function again on the external control terminal.
(g) Pump pressure in bar
(h) Pressure of the agitator in bar
(i) Cleaning pressure in bar
