3.2.20.2 Parameter settings
F
F
b
d
a
Central electrics
c
(a) Sprayer implement control unit
(b) Control unit for section control
(c) Central electrics
(d) Control unit for BoomControl
Various areas can be accessed via the sym-
bols. Additional pages can be accessed by
scrolling.
e
f
(e) Control unit for water valves
(f) External control terminal
¾ Not all areas are available, depending on
the machine’s equipment!
¾ The submenus of the settings all follow the same layout (see example of sprayer design control
unit).
54 55
