3.2.20 Diagnostics / Settings / Information
F
a b c
d e f
Various areas can be reached through the
symbols:
(a) Diagnostics
(b) Settings
(c) "Teaching": Teaching, saving sensor
value
(d) Manual folding (emergency folding)
(e) Machine geometry
(f) Access to protected area
3.2.20.1 Diagnostics
F
Inputs
a
Outputs
b
Messages
c
Version
d
(a) Input signals
(b) Output signals
(c) Messages
(d) Current version
Various areas can be accessed via the sym-
bols.
