3.2 Sub-pages sprayer implement
¾ Touch the symbol or control button to access the sub-page.
3.2.1 BoomControl folding boom control
F
Yellow: BoomControl is acti-
vated
Green: BoomControl active
a
d
e
b
c
(a) Preselect centre part control on/o.
¾ If the control is deactivated (checkmark
not set), the folding boom height is not
controlled by the parallelogram. The
status is displayed on the main page.
(b) Preselect control outside wing left on/o
(option with BoomControl Pro Plus)
(c) Preselect control outside wing right on/o
(option with BoomControl Pro Plus)
If the checkmarks are placed, the outside
wings are automatically adjusted to the pre-
selected height. If the checkmarks are not
set, the stored value is used to control the
folding position.
Generally, Boom Control Pro Plus adjusts the
outside wings only to the preselected working
height when the sprayer's main switch has
been turned on and the nozzles are open.
12 13
