NOTE
The correct resting of the spraying boom in the transport position must be veried on the control
terminal and the machine before road travel!
Flawless interlocking of the slope compensation and folding boom must be ensured!
NOTE
The sensor values of the respective function are highlighted in colour depending on reaching the
expected position.
white Function was not yet actuated
yellow Sensor at intermediate position (start or end position not reached)
green End position reached
red Sensor value faulty / defective
