Engine consumption indicator
Tank bar
AdBlue level indicator (for exhaust gas level IV or higher)
Fuel level indicator
Vehicle status bar
Ladder status
¾ Unfolded or folded or in between (position of the ladder is uncertain,
symbol ashes)
NOTE
¾ Check visually before starting to drive whether ladder is folded up!
Active device for speed default
¾ Pedal, joystick, cruise control 1, cruise control 2 or headland man-
agement
Seat switch
¾ Indicates whether the seat is occupied
Parking brake
¾ On or O
Direction of travel
¾ Forward
¾ Backward
¾ Neutral
General status bar
a b c
d
0°C
30/08/2019
10:48
Outside temperature, date, time
(a) current outside temperature
(b) current date
(c) current time
(d) engine warning lamps:
¾ Warning symbols light up here when the
error is active
¾ Refer to the Messages section in this regard
74 75
