2
12504 chassis view
Figure 1 12504 front view
(1) MPU slots (slots 0 to 1) (2) LPU slots (slots 2 to 5) (3) Power frame cover
(4) Power switch cover (5) ESD-preventive wrist strap port
NOTE:
The power frame cover protects the power frame air filter and the power frame slots.
