Table 39 OAA card specifications
Model Interfaces
Supported interface
modules
LST1FW2A1
• One console port
• One CF card slot, supporting a 256M, 512M, or 1G CF
card
• Two USB ports
• Two 10/100/1000 BASE-T copper ports
• Two GE combo interfaces
GE SFP modules
LST1FW3A1
• One console port
• One CF card slot, supporting a 256M CF card
• Two USB ports (reserved for hardware, not supporting
software)
• Two GE combo interfaces
GE SFP modules
Power components
Select AC or DC power components according to the power supply mode of your switch.
• Choose power supplies based on your actual needs. Make sure the maximum output power of the
power supplies exceeds the system power consumption (HP recommends reserving a certain power
de-rating value). For the maximum output power of a single power supply, see Table 41.
• HP r
ecommends you to configure N+1 or N+M power supply redundancy.
• To use AC power supply, select the specific 16 A AC power cords. For the 16A AC power cords
used in different countries or regions, see Table 42.
Table 40 Power system ordering gui
de
Model
Power
supply
mode
Power components Configured quantity
PSE9000-A1 AC
AC power frame
• 1 fo r t h e 1250 4 o r 125 0 8
• 2 for the 12518
PEM One is required for each power frame
Power monitor module One is required for each power frame
AC power supply
• 6 at most for the 12504 or 12508
• 12 at most for the 12518
PSE9000-D DC
DC power frame
• 1 fo r t h e 1250 4 o r 125 0 8
• 2 for the 12518
Power monitor module One is required for each power frame
DC power supply
• 6 at most for the 12504 or 12508
• 12 at most for the 12518
