3. Position the air filter to the right place, and fasten the fastening screws on the air filter.

Figure 64 Removing the power frame air filter

For a 12508 or 12518

To clean the power frame air filter:

1. Loosen the fastening screws on the air filter and remove the air filter from the power frame.

Figure 65 Removing the power supply air filter

(1) Power frame air filter (2) Fastenin

screws


