135
VLAN ID Protocol Index Protocol Type
======================================================
100 1 ipv4
200 1 ipv6
Interface: GigabitEthernet 1/0/2
VLAN ID Protocol Index Protocol Type
======================================================
100 1 ipv4
200 1 ipv6
Configuration guidelines
Protocol-based VLAN configuration applies only to hybrid ports.
Configuring IP subnet-based VLANs
In this approach, packets are assigned to VLANs based on their source IP addresses and subnet masks.
A port configured with IP subnet-based VLANs assigns a received untagged packet to a VLAN based on
the source address of the packet.
This feature is used to assign packets from the specified IP subnet or IP address to a specific VLAN.
Configuration procedure
IMPORTANT:
This feature is applicable only on hybrid ports.
To configure an IP subnet-based VLAN:
Ste
Command
Remarks
1. Enter system view.
system-view N/A
2. Enter VLAN view.
vlan vlan-id N/A
3. Associate an IP subnet
with the VLAN.
ip-subnet-vlan [ ip-subnet-index ] ip
ip-address [ mask ]
The IP subnet or IP address to be
associated with a VLAN cannot be a
multicast subnet or a multicast address.
4. Return to system view.
quit N/A
