HP 5120 EI Series User Manual

72
Task Remarks
Configuring the maximum port rate Optional
Configuring edge ports Optional
Configuring path costs of ports Optional
Configuring the port priority Optional
Configuring the port link type Optional
Configuring the mode a port uses to recognize/send MSTP
packets
Optional
Enabling outputting port state transition information Optional
Enabling the spanning tree feature Required
Performing mCheck Optional
Configuring TC snooping Optional
Configuring protection functions Optional
PVST configuration task list
Task Remarks
Configuring
the root
bridge
Setting the spanning tree mode
Required
Configure the device to operate in PVST
mode.
Configuring the root bridge or a secondary
root bridge
Optional
Configuring the device priority Optional
Configuring the network diameter of a
switched network
Optional
Configuring spanning tree timers Optional
Configuring the timeout factor Optional
Configuring the maximum port rate Optional
Configuring edge ports Optional
Configuring the port link type Optional
Enabling outputting port state transition
information
Optional
Enabling the spanning tree feature Required
Configuring
the leaf
nodes
Setting the spanning tree mode
Required
Configure the device to operate in PVST
mode.
Configuring the device priority Optional
Configuring the timeout factor Optional
Configuring the maximum port rate Optional
