181
Ste
p
Command Remarks
11. Enter Ethernet interface
view or port group view of
the customer network-side
port.
• Enter Ethernet interface view:
interface interface-type
interface-number
• Enter port group view:
port-group manual port-group-name
Use either command.
12. Enable basic QinQ.
qinq enable N/A
13. Apply the QoS policy to the
incoming traffic.
qos apply policy policy-name inbound N/A
Configuring the TPID value in VLAN tags
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Configure the TPID
value.
qinq ethernet-type hex-value
Optional.
By default, the TPID value is 0x8100.
The configuration applies to all ports.
NOTE:
The TPID value configured on the HP 5120 EI Switch Series applies to both the CVLAN tags and the
SVLAN tags.
QinQ configuration examples
Basic QinQ configuration example
Network requirements
As shown in Figure 62:
• The two branches of Company A, Site 1 and Site 2, are connected through the service provider
network and use CVLANs 10 through 70. The two branches of Company B, Site 3 and Site 4, are
connected through the service provider network and use CVLANs 30 through 90.
• PE 1 and PE 2 are edge devices on the service provider network and are connected through
third-party devices with a TPID value of 0x8200.
Configure the edge and third-party devices to enable communication between the branches of Company
A through SVLAN 100, and communication between the branches of Company B through SVLAN 200.
