HP LD4201 - Configuration of Frame; Lead Code; Repeat Code; Bit Description

Configuration of frame
ł 1st frame
ł
Repeat frame
Lead code
Repeat code
Bit description
ł Bit “0”
0.56 ms
1.12 ms
ł Bit “1”
0.56 ms
2.24 ms
Frame interval: Tf
The waveform is transmitted as long as a key is depressed.
