Toolbar
The toolbar has a collection of useful functions.
Search
Search searches the display(s) connected to the network and adds them.
NOTE: Displays connected to serial communication will not be detected.
Setting
Setting allows you to set a communication method to connect to the signage display. You can select
either Ethernet (Network) or RS-232 serial communication depending on your environment.
NOTE:
Ethernet Network
To use Ethernet (network) communication:
1. Under Communication Select, select Network.
2. Click OK to complete.
RS-232C Serial Communication
To use RS-232-C serial communication:
1. Under Communication Select, select Serial. Adjust the serial communication settings to fit your
environment.
Item Description
Port Communication port (COM1 - COM9), Default: COM1
Baud Rate Communication speed (2400 - 115200), Default: 9600
Data Communication data (Data5 - Data8), Default: Data8
Parity Parity check (even, odd, none), Default: none
Stop The number of stop bits (0 - 1), Default: 1
Flow Control Data flow (Xon/Xoff, hardware, none), Default: none
2. Click OK to complete.
Connect
Connect is used to reconnect the display to the network manually when the display is disconnected.
74 Chapter 6 Installing HP Network Sign Manager ENWW
