The following describes how to reconnect a specified monitor to the network.
1. Select a display or display group to reconnect.
2. Click Connect.
NOTE: This function does not support a display connected with serial communication.
Refresh
Refresh is used to refresh the information in the selected control tab. For example, select the
Information tab, and then click Refresh. The information for the selected display or display group is
updated.
Similarly, to view the current display settings, select a display, select the A/V tab, and then click
Refresh
Message
Message is used to display a message you want on the display. You specify a message to be
displayed constantly in a specific position of the screen.
NOTE: Up to 60 characters are allowed in the message field. Only alphanumeric characters can be
entered.
The following describes how to use the Message function:
1. From Network Communication, select a display or display group on which you want to display
a message.
2. On the toolbar, click Message. The Message Setting dialog appears.
NOTE: If a display or display group has not been selected, the Message Setting dialog does
not appear.
3. Set the position, color, and content of the message displayed on the monitor
Item Description
Message Align Sets the position where the message is displayed.
Message Color Selects a color of the message displayed.
Message Send Enters the content of the message displayed.
4. Click Send to send the created message.
Item Description
Send Displays the created message on the selected display or display group.
Clear Clears the text entered in the Message Send field.
Close Closes the Message Send dialog.
ENWW
Toolbar
75
