Display registration
HP Network Sign Manager allows you to add and manage multiple monitors with both Ethernet and
serial communications.
Registering a networked display
The following describes how to add a monitor with Ethernet communication.
1. Click Search on the toolbar. The Signage Monitor Search dialog appears.
2. Specify a Search Method in the Signage Monitor Search dialog. There are two search
methods:
ł Subnet (Broadcasting) — Automatically searches monitor(s) on the same local network to
which the computer running HP Network Sign Manager is connected.
ł Enter IP address manually — An IP address for the monitor needs to be entered manually
to add it to HP Network Sign Manager. Monitors connected to the external network can also
be connected.
NOTE: Sharing the same network means using the same default gateway and subnet
host.
3. Click Search to search for a monitor. When the search is complete, the Completed message
appears under Status.
4. When the search is complete, click Close to close the dialog. You can see the searched
monitor(s) added in the Add Monitor pane of the main window.
The added monitor is displayed with three different icons depending on the current status as shown below:
Successfully connected to HP Network Sign Manager
Disconnected from HP Network Sign Manager
When the fan, panel, or temperature is not normal
58 Chapter 6 Installing HP Network Sign Manager ENWW
