by protecting, for example, against power source failures or accidentally tripped circuit breakers.
The server can receive AC input from two different AC power sources.
System AC Power Specifications
Power Cords
Table B-3 lists the various power cables available for use with a HP Integrity rx7620 server. Each
power cord is 15 feet (4.5 meters) in length with a IEC 60320-1 C19 female connector attached to
one end.
Table B-3 Power Cords
Where UsedDescriptionPart Number
International-OtherStripped end, 240 volt8120-6895
International-EuropeMale IEC309, 240 volt8120-6897
ChinaMale GB-1002, 240 volts8121-0070
North America/JapanMale NEMA L6-20, 240 volt8120-6903
System Power Specifications
Table B-4 lists the AC power requirements for an HP Integrity rx7620 server. These tables provide
information to help determine the amount of AC power needed for your computer room.
Table B-4 AC Power Specifications
CommentsValueRequirements
200/208/220/230/240 (VAC rms)Nominal input voltage
50 - 60 (Hz)Frequency range (minimum -
maximum)
1Number of phases
Per line cord12 ampsMaximum input current
Per line cord30 A peak for 15 msMaximum inrush current
At all loads of 50% - 100% of supply rating
At all loads 0f 25% - 50% of supply rating
>0.98
>0.95
Power factor correction
Per line cord<3.0 (ma)Ground leakage current (mA)
CommentsVAWattsPower Required (50 - 60 Hz)
See #1 below32203156Maximum Theoretical Power
12A @ 220 VAC, see note #22640---Marked Electrical Power
See note #320301989Typical Maximum Power
110 System Specifications
