Figure 3-3 Right Foam Block Position
7. Remove the cushions from the lower front and rear of the server. Do not disturb the side
cushions.
Figure 3-4 Foam Block Removal
8. Locate and identify the caster assemblies. Table 3-2 shows the caster part numbers.
NOTE: The caster part number is stamped on the caster mounting plate.
Table 3-2 Caster Part Numbers
Part NumberCaster
A6753-04001Right front
A6753-04005Right rear
Installing the Wheel Kit 43
