HP rp7420 Service Manual

3 Installing Accessories
This chapter describes how to install components into the server that are not factory integrated.
Installing the Wheel Kit
Compare the packing list shown in Table 3-1 with the contents of the wheel kit before installing
the wheels.
Table 3-1 Wheel Kit Packing List
QuantityDescriptionPart Number
1Wheel Kit consisting of the following components:A6753-04013
1Right side caster coverA6753-04002
1Left side caster coverA6753-04003
1Top coverA6753-04004
2Caster coverA6753-00007
1Right front caster assemblyA6753-04001
1Right rear caster assemblyA6753-04005
1Left front caster assemblyA6753-04006
1Left rear caster assemblyA6753-04007
4M4 x 0.7 8mm T15 steel zinc machine screw (used to attach
each caster to the chassis)
0515-2478
1Plywood unloading rampA6093-44013
2Phillips head wood screw (used to attach the ramp to the
pallet)
Not applicable
Required Tools
The following list provides the installer with the recommended tools to perform the wheel kit
installation.
• Diagonal side cutters
• Safety glasses
• Torx screwdriver with T-15 bit
• Phillips head screwdriver
WARNING! Wear protective glasses while cutting the plastic bands around the shipping
container. These bands are under tension. When cut, they can spring back and cause serious eye
injury.
To attach the wheels to the server, follow these steps:
1. Cut and remove the polystrap bands securing the HP server to the pallet.
2. Lift the carton top from the cardboard tray resting on the pallet.
3. Remove the bezel kit carton and the top cushions from the pallet (Figure 3-1).
Installing the Wheel Kit 41
