Unpacking a Non-Racked Server
NOTE: If this server was delivered with a wheel kit, proceed to Chapter 3 (page 41).
NOTE: HP recommends the use of a lifter, such as a RONI Company model 17000 SP 400 lifting
device, when moving a non-racked system (Figure 2-5). If no lifter is available, install the lift
handle panels provided with the system.
Unloading With a Lifter
To unload the server from the pallet using a lifter, follow these steps.
WARNING! Use caution when using a lifter. Because of the weight of the server, it must be
centered on the lifter forks before raising it off the pallet to avoid injury.
Never extend more than one server from the same cabinet while installing or servicing another
server product. Failure to follow these instructions could result in the cabinet tipping over.
Figure 2-5 RONI Lifter
Unpacking a Non-Racked Server 35
