Figure 3-6 Securing Each Caster Cover to the Server
17. Wheel kit installation is complete when both caster covers are attached to the server and the
front bezel and all covers are installed.
Figure 3-7 Server With Wheel Kit Installed
PCI-X Card Cage Assembly I/O Cards
A number of PCI and PCI-X I/O cards are supported in the HP 9000 rp7420 server. Known cards
supported at the release of this manual are shown in Table 3-3.
Table 3-3 HP 9000 rp7420 server I/O Cards
Number of Cards Supported (B
- Bootable)
Card DescriptionPart Number
15FDDI Dual AttachA3739B
15Next Generation 1000B-SXA6847A
15Next Generation 1000B-TA6825A
PCI-X Card Cage Assembly I/O Cards 45
